Today’s prompt is Pictogram. I decided to replace the dots in a dot-density histogram with emojis that represent how many standard deviations from the mean each observation sits.

Building the data

First, generate some normally distributed data and compute the standard deviation bins:

data_hist <- {
  set.seed(1)
  tibble(x = rnorm(500, mean = 100, sd = 8))
}

sd_of_data   <- sd(data_hist$x)
mean_of_data <- mean(data_hist$x)

Build a dot-density histogram to extract the dot positions, then label each dot by its distance from the mean:

gg_hist_dot_plot <- data_hist |>
  ggplot(aes(x = x)) +
  geom_dotplot(binwidth = 1, method = "dotdensity", dotsize = 1, position = "dodge", binpositions = "bygroup")

build_gg <- ggplot_build(gg_hist_dot_plot)

Warning: `position_dodge()` requires non-overlapping x intervals.

vec_emojis <- c(
  "3+" = emo::ji("scream"),
  "3"  = emo::ji("fearful"),
  "2"  = emo::ji("confused"),
  "1"  = emo::ji("smile")
)

data_emoji_positions <- build_gg$data |>
  as.data.frame() |>
  as_tibble() |>
  select(x, xmin, xmax, y, stackpos) |>
  mutate(sds_from_mean = case_when(
    x < (mean_of_data - 3 * sd_of_data) ~ "3+",
    x <= (mean_of_data - 2 * sd_of_data) ~ "3",
    x <= (mean_of_data - 1 * sd_of_data) ~ "2",
    x <= (mean_of_data + 1 * sd_of_data) ~ "1",
    x <= (mean_of_data + 2 * sd_of_data) ~ "2",
    x <= (mean_of_data + 3 * sd_of_data) ~ "3",
    x > (mean_of_data + 3 * sd_of_data)  ~ "3+"
  )) |>
  mutate(emoji_symbol = vec_emojis[sds_from_mean])

The chart

A helper function fills the normal curve behind the dots:

hist_function <- function(x) { dnorm(x, mean = 100, sd = 8) * 700 }

geom_dnorm_fill <- function(xlim, fill_color, alpha = 0.5) {
  geom_area(
    stat = "function",
    fun = hist_function,
    fill = fill_color,
    alpha = alpha,
    xlim = xlim
  )
}

gg_emoji_histogram <- data_emoji_positions |>
  ggplot(aes(x, y = stackpos)) +
  geom_dnorm_fill(c(mean_of_data - 4 * sd_of_data, mean_of_data + 4 * sd_of_data), viridis::viridis(4)[4]) +
  geom_dnorm_fill(c(mean_of_data - 3 * sd_of_data, mean_of_data + 3 * sd_of_data), viridis::viridis(4)[3]) +
  geom_dnorm_fill(c(mean_of_data - 2 * sd_of_data, mean_of_data + 2 * sd_of_data), viridis::viridis(4)[2]) +
  geom_dnorm_fill(c(mean_of_data - 1 * sd_of_data, mean_of_data + 1 * sd_of_data), viridis::viridis(4)[1]) +
  geom_richtext(
    data = tibble(label = str_glue(
      "{emo::ji('smile')} represent <span style='color:{viridis::viridis(4)[1]};font-weight:bold'>68% of the data</span>",
      "<br>",
      "{emo::ji('confused')} represent <span style='color:{viridis::viridis(4)[2]};font-weight:bold'>95% of the data</span>",
      "<br>",
      "{emo::ji('fearful')} represent <span style='color:{viridis::viridis(4)[3]};font-weight:bold'>99.7% of the data</span>",
      "<br>",
      "{emo::ji('scream')} represent <span style='color:{viridis::viridis(4)[4]};font-weight:bold'>the rest of the data</span>"
    )),
    aes(label = label),
    family = "DM Sans",
    label.padding = unit(c(0.5, 0.5, 0.5, 0.5), "lines"),
    label.margin  = unit(c(0, 0, 0, 0), "lines"),
    size = 7,
    x = 110,
    y = 30,
    hjust = 0
  ) +
  geom_curve(
    data = tibble(x = 120, y = 15, xend = max(data_emoji_positions$x) - 1, yend = 1),
    aes(x, y, yend = yend, xend = xend),
    arrow = arrow(length = unit(0.03, "npc")),
    curvature = 0.2,
    angle = 90
  ) +
  geom_richtext(
    data = tibble(x = 115, y = 15, label = "Yup, that's me. You're probably<br>wondering how I ended up in<br> this situation..."),
    aes(x, y, label = label),
    label.colour = "transparent",
    hjust = 0,
    family = "Comic Sans MS",
    label.padding = unit(c(0, 0.25, 0.25, 0.25), "lines"),
    label.margin  = unit(c(0, 0, 0, 0), "lines"),
    size = 6
  ) +
  geom_richtext(
    aes(label = emoji_symbol),
    size = 5,
    fill = NA,
    label.color = NA,
    label.padding = grid::unit(rep(0, 4), "pt")
  ) +
  scale_y_continuous(expand = expansion(add = c(0, 5))) +
  labs(
    title = "#30DayChartChallenge 2022-04-02 Pictogram: Emojis and Standard Deviations",
    subtitle = "With apologies to everyone I present the <i>Emoji Standard Deviation Chart</i>",
    x = "",
    y = ""
  ) +
  theme_ipsum_rc(grid = "") +
  theme(
    plot.title    = element_text(family = "Arvo"),
    plot.subtitle = element_markdown(),
    axis.text.x   = element_blank(),
    axis.text.y   = element_blank(),
    plot.background = element_rect(fill = "#4B54CE")
  )

gg_emoji_histogram
